EDK2获取Protocol总结

时间轴

时间轴

2025-02-25

1. 添加了 OpenProtocol,HandleProtocol,LocateProtocol,OpenProtocolInformation,CloseProtocol

本文介绍了EDK2中获取Protocol的几种常用接口，包括OpenProtocol、HandleProtocol、LocateProtocol、OpenProtocolInformation和CloseProtocol。OpenProtocol需要指定AgentHandle、ControllerHandle和Attributes；HandleProtocol与OpenProtocol类似，但无需指定这些参数；ProtocolsPerHandle用于通过设备句柄检索其上安装的所有Protocol接口GUID；LocateProtocol不关心Protocol具体所在设备，而是在系统中顺序查找并返回第一个匹配的Protocol实例；OpenProtocolInformation和CloseProtocol则分别用于查询已打开协议的信息和关闭协议。

---

UefiSpec.h 中定义了 Protocol 相关的接口:

EFI_HANDLE_PROTOCOL HandleProtocol;

EFI_REGISTER_PROTOCOL_NOTIFY RegisterProtocolNotify;

EFI_LOCATE_HANDLE LocateHandle;

EFI_LOCATE_DEVICE_PATH LocateDevicePath;

EFI_OPEN_PROTOCOL OpenProtocol;

EFI_CLOSE_PROTOCOL CloseProtocol;

EFI_OPEN_PROTOCOL_INFORMATION OpenProtocolInformation;

EFI_PROTOCOLS_PER_HANDLE ProtocolsPerHandle;

EFI_LOCATE_HANDLE_BUFFER LocateHandleBuffer;

EFI_LOCATE_PROTOCOL LocateProtocol;

EFI_INSTALL_PROTOCOL_INTERFACE InstallProtocolInterface;

EFI_REINSTALL_PROTOCOL_INTERFACE ReinstallProtocolInterface;

EFI_UNINSTALL_PROTOCOL_INTERFACE UninstallProtocolInterface;

EFI_INSTALL_MULTIPLE_PROTOCOL_INTERFACES InstallMultipleProtocolInterfaces;

EFI_UNINSTALL_MULTIPLE_PROTOCOL_INTERFACES UninstallMultipleProtocolInterfaces;

///
/// EFI Boot Services Table.
///
typedef struct {
  ///
  /// The table header for the EFI Boot Services Table.
  ///
  EFI_TABLE_HEADER                              Hdr;

  //
  // Task Priority Services
  //
  EFI_RAISE_TPL                                 RaiseTPL;
  EFI_RESTORE_TPL                               RestoreTPL;

  //
  // Memory Services
  //
  EFI_ALLOCATE_PAGES                            AllocatePages;
  EFI_FREE_PAGES                                FreePages;
  EFI_GET_MEMORY_MAP                            GetMemoryMap;
  EFI_ALLOCATE_POOL                             AllocatePool;
  EFI_FREE_POOL                                 FreePool;

  //
  // Event & Timer Services
  //
  EFI_CREATE_EVENT                              CreateEvent;
  EFI_SET_TIMER                                 SetTimer;
  EFI_WAIT_FOR_EVENT                            WaitForEvent;
  EFI_SIGNAL_EVENT                              SignalEvent;
  EFI_CLOSE_EVENT                               CloseEvent;
  EFI_CHECK_EVENT                               CheckEvent;

  //
  // Protocol Handler Services
  //
  EFI_INSTALL_PROTOCOL_INTERFACE                InstallProtocolInterface;
  EFI_REINSTALL_PROTOCOL_INTERFACE              ReinstallProtocolInterface;
  EFI_UNINSTALL_PROTOCOL_INTERFACE              UninstallProtocolInterface;
  EFI_HANDLE_PROTOCOL                           HandleProtocol;
  VOID                                          *Reserved;
  EFI_REGISTER_PROTOCOL_NOTIFY                  RegisterProtocolNotify;
  EFI_LOCATE_HANDLE                             LocateHandle;
  EFI_LOCATE_DEVICE_PATH                        LocateDevicePath;
  EFI_INSTALL_CONFIGURATION_TABLE               InstallConfigurationTable;

  //
  // Image Services
  //
  EFI_IMAGE_LOAD                                LoadImage;
  EFI_IMAGE_START                               StartImage;
  EFI_EXIT                                      Exit;
  EFI_IMAGE_UNLOAD                              UnloadImage;
  EFI_EXIT_BOOT_SERVICES                        ExitBootServices;

  //
  // Miscellaneous Services
  //
  EFI_GET_NEXT_MONOTONIC_COUNT                  GetNextMonotonicCount;
  EFI_STALL                                     Stall;
  EFI_SET_WATCHDOG_TIMER                        SetWatchdogTimer;

  //
  // DriverSupport Services
  //
  EFI_CONNECT_CONTROLLER                        ConnectController;
  EFI_DISCONNECT_CONTROLLER                     DisconnectController;

  //
  // Open and Close Protocol Services
  //
  EFI_OPEN_PROTOCOL                             OpenProtocol;
  EFI_CLOSE_PROTOCOL                            CloseProtocol;
  EFI_OPEN_PROTOCOL_INFORMATION                 OpenProtocolInformation;

  //
  // Library Services
  //
  EFI_PROTOCOLS_PER_HANDLE                      ProtocolsPerHandle;
  EFI_LOCATE_HANDLE_BUFFER                      LocateHandleBuffer;
  EFI_LOCATE_PROTOCOL                           LocateProtocol;
  EFI_INSTALL_MULTIPLE_PROTOCOL_INTERFACES      InstallMultipleProtocolInterfaces;
  EFI_UNINSTALL_MULTIPLE_PROTOCOL_INTERFACES    UninstallMultipleProtocolInterfaces;

  //
  // 32-bit CRC Services
  //
  EFI_CALCULATE_CRC32                           CalculateCrc32;

  //
  // Miscellaneous Services
  //
  EFI_COPY_MEM                                  CopyMem;
  EFI_SET_MEM                                   SetMem;
  EFI_CREATE_EVENT_EX                           CreateEventEx;
} EFI_BOOT_SERVICES;

OpenProtocol

OpenProtocol

// MdePkg/Include/Uefi/UefiSpec.h

#define EFI_OPEN_PROTOCOL_BY_HANDLE_PROTOCOL   0x00000001
#define EFI_OPEN_PROTOCOL_GET_PROTOCOL         0x00000002
#define EFI_OPEN_PROTOCOL_TEST_PROTOCOL        0x00000004
#define EFI_OPEN_PROTOCOL_BY_CHILD_CONTROLLER  0x00000008
#define EFI_OPEN_PROTOCOL_BY_DRIVER            0x00000010
#define EFI_OPEN_PROTOCOL_EXCLUSIVE            0x00000020
/*
  Queries a handle to determine if it supports a specified protocol. If the protocol is supported by the
  handle, it opens the protocol on behalf of the calling agent.

  @param[in]   Handle           The handle for the protocol interface that is being opened.
  @param[in]   Protocol         The published unique identifier of the protocol.
  @param[out]  Interface        Supplies the address where a pointer to the corresponding Protocol
                                Interface is returned.
  @param[in]   AgentHandle      The handle of the agent that is opening the protocol interface
                                specified by Protocol and Interface.
  @param[in]   ControllerHandle If the agent that is opening a protocol is a driver that follows the
                                UEFI Driver Model, then this parameter is the controller handle
                                that requires the protocol interface. If the agent does not follow
                                the UEFI Driver Model, then this parameter is optional and may
                                be NULL.
  @param[in]   Attributes       The open mode of the protocol
  interface specified by Handle
                                and Protocol.

  @retval EFI_SUCCESS           An item was added to the open list for the protocol interface, and the
                                protocol interface was returned in Interface.
  @retval EFI_UNSUPPORTED       Handle does not support Protocol.
  @retval EFI_INVALID_PARAMETER One or more parameters are invalid.
  @retval EFI_ACCESS_DENIED     Required attributes can't be supported in current environment.
  @retval EFI_ALREADY_STARTED   Item on the open list already has required attributes whose agent
                                handle is the same as AgentHandle.
*/
typedef
EFI_STATUS
(EFIAPI *EFI_OPEN_PROTOCOL)(
  IN  EFI_HANDLE                Handle,
  IN  EFI_GUID                  *Protocol,
  OUT VOID                      **Interface  OPTIONAL,
  IN  EFI_HANDLE                AgentHandle,
  IN  EFI_HANDLE                ControllerHandle,
  IN  UINT32                    Attributes
  );

示例:

#include <Guid/FileInfo.h>
#include <Library/BaseMemoryLib.h>
#include <Library/CacheMaintenanceLib.h>
#include <Library/MemoryAllocationLib.h>
#include <Library/UefiBootServicesTableLib.h>
#include <Library/UefiLib.h>
#include <Protocol/SimpleFileSystem.h>

EFI_STATUS
ReadFileByName(IN CHAR16 *FileName, OUT UINT8 **FileData, OUT UINTN *FileSize) {
  EFI_FILE_INFO *FileInfo;
  UINTN FileInfoSize;
  EFI_FILE_PROTOCOL *FileHandle = NULL;
  EFI_SIMPLE_FILE_SYSTEM_PROTOCOL *SimpleFileSystem;
  EFI_FILE_PROTOCOL *Root;
  EFI_STATUS Status;
  UINTN HandleCount = 0;
  UINTN HandleIndex = 0;
  EFI_HANDLE *HandleBuffer = NULL;
  // find all handles of SimpleFileSystemProtocol
  Status =
      gBS->LocateHandleBuffer(ByProtocol, &gEfiSimpleFileSystemProtocolGuid,
                              NULL, &HandleCount, &HandleBuffer);
  if (EFI_ERROR(Status) || HandleCount == 0) {
    Print(L"Locate SimpleFileSystemProtocolHandle Buffer error");
    return Status;
  }

  for (HandleIndex = 0; HandleIndex < HandleCount; HandleIndex++) {
    Status = gBS->OpenProtocol(HandleBuffer[HandleIndex],
                               &gEfiSimpleFileSystemProtocolGuid,
                               (VOID **)&SimpleFileSystem, gImageHandle, NULL,
                               EFI_OPEN_PROTOCOL_BY_HANDLE_PROTOCOL);
    if (EFI_ERROR(Status)) {
      Print(L"Open SimpleFileSystemProtocol error,at HandleIndex %d",
            HandleIndex);
      continue;
    }
    Status = SimpleFileSystem->OpenVolume(SimpleFileSystem, &Root);
    if (EFI_ERROR(Status)) {
      Print(L"Open Root Volume error at HandleIndex%d", HandleIndex);
      gBS->CloseProtocol(HandleBuffer[HandleIndex],
                         &gEfiSimpleFileSystemProtocolGuid, gImageHandle, NULL);
      continue;
    }
    // 1.打开文件，获取文件句柄FileHandle
    Status = Root->Open(Root, &FileHandle, FileName, EFI_FILE_MODE_READ, 0);
    if ((FileHandle == NULL) || (EFI_ERROR(Status))) {
      Print(L"Open file %s failed at HandleIndex%d\n", FileName, HandleIndex);
      Root->Close(Root);
      gBS->CloseProtocol(HandleBuffer[HandleIndex],
                         &gEfiSimpleFileSystemProtocolGuid, gImageHandle, NULL);
      continue;
    }
    // else find the target handle
    Print(L"FileHandle: 0x%p at HandleIndex%d\n", FileHandle, HandleIndex);
    // 2.分配文件信息大小
    FileInfoSize = sizeof(EFI_FILE_INFO) + 1024;
    FileInfo = AllocateZeroPool(FileInfoSize);
    if (FileInfo == NULL) {
      Print(L"can not allocate %d size for FileInfo at HandleIndex%d\n",
            FileInfoSize, HandleIndex);
      FileHandle->Close(FileHandle);
      Root->Close(Root);
      gBS->CloseProtocol(HandleBuffer[HandleIndex],
                         &gEfiSimpleFileSystemProtocolGuid, gImageHandle, NULL);
      continue;
    }
    // 3.打开文件信息
    Status = FileHandle->GetInfo(FileHandle, &gEfiFileInfoGuid, &FileInfoSize,
                                 FileInfo);
    if (EFI_ERROR(Status)) {
      Print(L"Get FileInfo failed at HandleIndex%d\n", HandleIndex);
      FileHandle->Close(FileHandle);
      Root->Close(Root);
      gBS->CloseProtocol(HandleBuffer[HandleIndex],
                         &gEfiSimpleFileSystemProtocolGuid, gImageHandle, NULL);
      continue;
    }
    Print(L"FileInfo: 0x%p\n", FileInfo);
    // 4.预先分配文件大小
    *FileSize = (UINTN)FileInfo->FileSize + sizeof(CHAR16);
    *FileData = AllocateZeroPool(*FileSize);
    if (*FileData == NULL) {
      Print(L"locate file data size %d failed at HandleIndex%d\n", *FileSize,
            HandleIndex);
      FileHandle->Close(FileHandle);
      gBS->FreePool(FileInfo);  // 释放FileInfo
      Root->Close(Root);
      gBS->CloseProtocol(HandleBuffer[HandleIndex],
                         &gEfiSimpleFileSystemProtocolGuid, gImageHandle, NULL);
      continue;
    } else {
      Print(L"size of %s is %d\n", FileName, *FileSize);
      Print(L"FileData: 0x%p\n", *FileData);
    }

    // 5.读取文件
    Status = FileHandle->Read(FileHandle, FileSize, (VOID *)*FileData);
    if (EFI_ERROR(Status)) {
      Print(L"open %s file failed at HandleIndex%d\n", FileName, HandleIndex);
      FileHandle->Close(FileHandle);
      gBS->FreePool(FileInfo);  // 释放FileInfo
      Root->Close(Root);
      gBS->CloseProtocol(HandleBuffer[HandleIndex],
                         &gEfiSimpleFileSystemProtocolGuid, gImageHandle, NULL);
      // gBS->FreePool((VOID *)FileData);
      continue;
    } else {
      Print(L"open %s file success at HandleIndex%d\n", FileName, HandleIndex);
    }
    FileHandle->Close(FileHandle);
    Print(L"FileHandle is freed normally at HandleIndex%d\n", HandleIndex);
    gBS->FreePool(FileInfo);  // 释放FileInfo
    Print(L"FileInfo is freed normally at HandleIndex%d\n", HandleIndex);
    Root->Close(Root);
    gBS->CloseProtocol(HandleBuffer[HandleIndex],
                       &gEfiSimpleFileSystemProtocolGuid, gImageHandle, NULL);
    Print(L"Operation Success at HandleIndex%d\n", HandleIndex);
    break;
  }

  if (HandleBuffer != NULL) {
    gBS->FreePool(HandleBuffer);
  }
  return Status;
}

HandleProtocol

UEFI_Spec_2.8

HandleProtocol的原型

相比于 OpenProtocol，不需要指定参数 AgentHandle、ControllerHandle 和 Attributes

/**
  Queries a handle to determine if it supports a specified protocol.

  @param[in]   Handle           The handle being queried.
  @param[in]   Protocol         The published unique identifier of the protocol.
  @param[out]  Interface        Supplies the address where a pointer to the corresponding Protocol
                                Interface is returned.

  @retval EFI_SUCCESS           The interface information for the specified protocol was returned.
  @retval EFI_UNSUPPORTED       The device does not support the specified protocol.
  @retval EFI_INVALID_PARAMETER Handle is NULL.
  @retval EFI_INVALID_PARAMETER Protocol is NULL.
  @retval EFI_INVALID_PARAMETER Interface is NULL.

**/
typedef
EFI_STATUS
(EFIAPI *EFI_HANDLE_PROTOCOL)(
  IN  EFI_HANDLE               Handle,
  IN  EFI_GUID                 *Protocol,
  OUT VOID                     **Interface
  );

例子：

#include <Library/DevicePathLib.h>
#include <Library/UefiBootServicesTableLib.h>
#include <Library/UefiLib.h>
#include <Protocol/LoadedImage.h>
#include <Uefi.h>

EFI_STATUS EFIAPI UefiMain(IN EFI_HANDLE ImageHandle,
                           IN EFI_SYSTEM_TABLE *SystemTable) {
  EFI_STATUS Status;
  EFI_LOADED_IMAGE_PROTOCOL *LoadedImage;
  Status = gBS->HandleProtocol(ImageHandle, &gEfiLoadedImageProtocolGuid,
                               (VOID **)&LoadedImage);
  if (Status == EFI_SUCCESS) {
    EFI_DEVICE_PATH_PROTOCOL *DevicePath;
    Status =
        gBS->HandleProtocol(ImageHandle, &gEfiLoadedImageDevicePathProtocolGuid,
                            (VOID **)&DevicePath);
    if(Status == EFI_SUCCESS){
      Print(L"Image device: %s\n",ConvertDevicePathToText(DevicePath,FALSE,TRUE));
      Print(L"Image file: %s\n", ConvertDevicePathToText(LoadedImage->FilePath,FALSE,TRUE));
      Print(L"Image Base: %X\n",LoadedImage->ImageBase);
      Print(L"Image Size: %X\n",LoadedImage->ImageSize);
    }else{
      Print(L"Can't get EFI_LOADED_IMAGE_PROTOCOL, Status=%r\n",Status);
    }
  }else{
    Print(L"Can't get EFI_DEVICE_PATH_PROTOCOL, Status=%r\n",Status);
  }
  return EFI_SUCCESS;
}

ProtocolsPerHandle

UEFI_Spec_2.8

ProtocolsPerHandle

通过设备句柄检索其上安装的所有 Protocol 接口 GUID

/**
  Retrieves the list of protocol interface GUIDs that are installed on a handle in a buffer allocated
  from pool.

  @param[in]   Handle              The handle from which to retrieve the list of protocol interface
                                   GUIDs.
  @param[out]  ProtocolBuffer      A pointer to the list of protocol interface GUID pointers that are
                                   installed on Handle.
  @param[out]  ProtocolBufferCount A pointer to the number of GUID pointers present in
                                   ProtocolBuffer.

  @retval EFI_SUCCESS           The list of protocol interface GUIDs installed on Handle was returned in
                                ProtocolBuffer. The number of protocol interface GUIDs was
                                returned in ProtocolBufferCount.
  @retval EFI_OUT_OF_RESOURCES  There is not enough pool memory to store the results.
  @retval EFI_INVALID_PARAMETER Handle is NULL.
  @retval EFI_INVALID_PARAMETER Handle is not a valid EFI_HANDLE.
  @retval EFI_INVALID_PARAMETER ProtocolBuffer is NULL.
  @retval EFI_INVALID_PARAMETER ProtocolBufferCount is NULL.

**/
typedef
EFI_STATUS
(EFIAPI *EFI_PROTOCOLS_PER_HANDLE)(
  IN  EFI_HANDLE      Handle,
  OUT EFI_GUID        ***ProtocolBuffer,
  OUT UINTN           *ProtocolBufferCount
  );

例子:

#include <Library/UefiLib.h>
#include <Library/UefiBootServicesTableLib.h>
#include <Library/MemoryAllocationLib.h>
#include <Uefi.h>

EFI_STATUS
EFIAPI
UefiMain(IN EFI_HANDLE ImageHandle, IN EFI_SYSTEM_TABLE *SystemTable) {
  Print(L"_______________\n");
  EFI_GUID **ProtocolGuidArray;
  UINTN ArrayCount;
  EFI_STATUS Status = gBS->ProtocolsPerHandle(ImageHandle,&ProtocolGuidArray,&ArrayCount);
  if(Status==EFI_SUCCESS){
    for(UINTN i =0;i<ArrayCount;i++){
      Print(L"%g\n",ProtocolGuidArray[i]);
    }
    FreePool(ProtocolGuidArray);
  }else{
    Print(L"ProtocolsPerHandle error: %r\n",Status);//%r打印EFI_STATUS错误码
  }
  return EFI_SUCCESS;
}

LocateProtocol

UEFI_Spec_2.8

LocateProtocol

与 HandleProtocol 和 OpenProtocol 不同，LocateProtocol 不关心 Protocol 在哪个设备上，它会在系统中顺序寻找句柄列表，返回找到的第一个 Protocol 实例

/**
  Returns the first protocol instance that matches the given protocol.

  @param[in]  Protocol          Provides the protocol to search for.
  @param[in]  Registration      Optional registration key returned from
                                RegisterProtocolNotify().
  @param[out]  Interface        On return, a pointer to the first interface that matches Protocol and
                                Registration.

  @retval EFI_SUCCESS           A protocol instance matching Protocol was found and returned in
                                Interface.
  @retval EFI_NOT_FOUND         No protocol instances were found that match Protocol and
                                Registration.
  @retval EFI_INVALID_PARAMETER Interface is NULL.
                                Protocol is NULL.

**/
typedef
EFI_STATUS
(EFIAPI *EFI_LOCATE_PROTOCOL)(
  IN  EFI_GUID  *Protocol,
  IN  VOID      *Registration  OPTIONAL,
  OUT VOID      **Interface
  );

例子:

EFI_STATUS
LoadFileByName(
	IN CHAR16 *FileName,
	OUT UINT8 **FileData,
	OUT UINTN *FileSize)
{
	EFI_STATUS Status;
	EFI_SIMPLE_FILE_SYSTEM_PROTOCOL *SimpleFileSystem;
	EFI_FILE_PROTOCOL *Root;
	EFI_FILE_PROTOCOL *FileHandle = NULL;
	EFI_FILE_INFO *FileInfo;
	UINTN FileInfoSize;
	UINTN TempBufferSize;
	VOID *TempBuffer;

	Status = gBS->LocateProtocol(&gEfiSimpleFileSystemProtocolGuid,
								 NULL, (VOID **)&SimpleFileSystem);
	if (EFI_ERROR(Status))
	{
		return Status;
	}

	//
	// Open the root directory
	//
	Status = SimpleFileSystem->OpenVolume(SimpleFileSystem, &Root);
	if (EFI_ERROR(Status))
	{
		return Status;
	}

	//
	// Open the file
	//
	Status = Root->Open(Root, &FileHandle, FileName,
						EFI_FILE_MODE_READ, 0);
	if ((FileHandle == NULL) || (EFI_ERROR(Status)))
	{
		Print(L"Open file %s failed !!\n", FileName);
		Root->Close(Root);
		return Status;
	}

	//
	// Get the file information
	//
	FileInfoSize = sizeof(EFI_FILE_INFO) + 1024;
	FileInfo = AllocateZeroPool(FileInfoSize);
	if (FileInfo == NULL)
	{
		FileHandle->Close(FileHandle);
		return Status;
	}

	Status = FileHandle->GetInfo(FileHandle, &gEfiFileInfoGuid,
								 &FileInfoSize,
								 FileInfo);
	if (EFI_ERROR(Status))
	{
		FileHandle->Close(FileHandle);
		gBS->FreePool(FileInfo);
		return Status;
	}

	//
	// Allocate buffer for the file data. The last CHAR16 is for L'\0'
	//
	TempBufferSize = (UINTN)FileInfo->FileSize + sizeof(CHAR16);
	TempBuffer = AllocateZeroPool(TempBufferSize);
	if (TempBuffer == NULL)
	{
		FileHandle->Close(FileHandle);
		gBS->FreePool(FileInfo);
		return Status;
	}

	gBS->FreePool(FileInfo);

	//
	// Read the file data to the buffer
	//
	Status = FileHandle->Read(FileHandle, &TempBufferSize, TempBuffer);
	if (EFI_ERROR(Status))
	{
		FileHandle->Close(FileHandle);
		gBS->FreePool(TempBuffer);
		return Status;
	}

	FileHandle->Close(FileHandle);

	*FileSize = TempBufferSize;
	*FileData = TempBuffer;
	return Status;
}

OpenProtocolInformation

UEFI_Spec_2.8

OpenProtocolInformation

///
/// EFI Open Protocol Information Entry
///
typedef struct {
  EFI_HANDLE    AgentHandle;
  EFI_HANDLE    ControllerHandle;
  UINT32        Attributes;
  UINT32        OpenCount;
} EFI_OPEN_PROTOCOL_INFORMATION_ENTRY;

/**
  Retrieves the list of agents that currently have a protocol interface opened.

  @param[in]   Handle           The handle for the protocol interface that is being queried.
  @param[in]   Protocol         The published unique identifier of the protocol.
  @param[out]  EntryBuffer      A pointer to a buffer of open protocol information in the form of
                                EFI_OPEN_PROTOCOL_INFORMATION_ENTRY structures.
  @param[out]  EntryCount       A pointer to the number of entries in EntryBuffer.

  @retval EFI_SUCCESS           The open protocol information was returned in EntryBuffer, and the
                                number of entries was returned EntryCount.
  @retval EFI_OUT_OF_RESOURCES  There are not enough resources available to allocate EntryBuffer.
  @retval EFI_NOT_FOUND         Handle does not support the protocol specified by Protocol.

**/
typedef
EFI_STATUS
(EFIAPI *EFI_OPEN_PROTOCOL_INFORMATION)(
  IN  EFI_HANDLE                          Handle,
  IN  EFI_GUID                            *Protocol,
  OUT EFI_OPEN_PROTOCOL_INFORMATION_ENTRY **EntryBuffer,
  OUT UINTN                               *EntryCount
  );

CloseProtocol

UEFI_Spec_2.8

CloseProtocol

/**
  Closes a protocol on a handle that was opened using OpenProtocol().

  @param[in]  Handle            The handle for the protocol interface that was previously opened
                                with OpenProtocol(), and is now being closed.
  @param[in]  Protocol          The published unique identifier of the protocol.
  @param[in]  AgentHandle       The handle of the agent that is closing the protocol interface.
  @param[in]  ControllerHandle  If the agent that opened a protocol is a driver that follows the
                                UEFI Driver Model, then this parameter is the controller handle
                                that required the protocol interface.

  @retval EFI_SUCCESS           The protocol instance was closed.
  @retval EFI_INVALID_PARAMETER 1) Handle is NULL.
                                2) AgentHandle is NULL.
                                3) ControllerHandle is not NULL and ControllerHandle is not a valid EFI_HANDLE.
                                4) Protocol is NULL.
  @retval EFI_NOT_FOUND         1) Handle does not support the protocol specified by Protocol.
                                2) The protocol interface specified by Handle and Protocol is not
                                   currently open by AgentHandle and ControllerHandle.

**/
typedef
EFI_STATUS
(EFIAPI *EFI_CLOSE_PROTOCOL)(
  IN EFI_HANDLE               Handle,
  IN EFI_GUID                 *Protocol,
  IN EFI_HANDLE               AgentHandle,
  IN EFI_HANDLE               ControllerHandle
  );
